Ametek Liquid Level Float Switch F-74090-2 - New Old Stock
New Old Stock
Item is stainless steel construction w/ float material designed for water
Qty. Available 1
Details
Ametek Liquid Level Float Switch F-74090-2 - New Old Stock
New Old Stock
Item is stainless steel construction w/ float material designed for water & salt water.
Part Number: F-74090-2
NSN: 5930-00-169-6121
| MRC |
Criteria |
Characteristic |
| ACYN |
AC VOLTAGE RATING |
110.0 VOLTS NOMINAL |
| ACZB |
FREQUENCY RATING |
60.0 HERTZ NOMINAL |
| FAAZ |
PHASE |
SINGLE/THREE |
| ACYR |
DC VOLTAGE RATING |
28.0 VOLTS NOMINAL |
| ALSF |
INTERNAL BATTERY ACCOMMODATION |
NOT INCLUDED |
| APGW |
CURRENT RATING AT MAXIMUM RATED VOLTAGE |
90.0 MILLIAMPERES RESISTIVE LOAD |
| BJKD |
CONTACT ARRANGEMENT |
SINGLE THROW, DOUBLE POLE, NORMALLY OPEN DRY |
| AGBD |
ELECTRICAL CONNECTION TYPE |
CONNECTOR RECEPTACLE |
| AEEE |
CONNECTOR MANUFACTURER CODE |
71468 |
| AGBG |
CONNECTOR IDENTIFICATION |
GS02-18-3P-111 |
| BJKG |
RELAY |
NOT INCLUDED |
| BJKH |
LIQUID TYPE FOR WHICH DESIGNED |
SEA WATER AND WATER |
| AWTN |
OPERATING TEMP RATING |
28.0 DEG FAHRENHEIT MINIMUM AND 300.0 DEG FAHRENHEIT MAXIMUM |
| AFLW |
ACTUATION METHOD |
BUOYANCY |
| AWAE |
FLOAT QUANTITY |
1 |
| BBJX |
MOUNTING POSITION |
VERTICAL |
| AXGY |
MOUNTING METHOD |
FLANGE |
| BJKP |
MOUNTING DIMENSIONS |
MTD BYFOUR 0.405 IN. MIN, 0.412 IN. MAX DIA HOLES EQUALLYSPACED ON A 2.375 IN. DIA BOLT CIRCLE |
| ABMK |
OVERALL WIDTH |
2.250 INCHES NOMINAL |
Loc: 38 G1, 165 (on E) Q. F-74090-2
